Description
Disc Size:
Outer Diameter: 292mm (11.5″)
Inner Diameter: 56.5mm (2.2″)
Thickness: 5mm
Hole Quantity: 5
Hole Size: 8.5mm
Hole Circumference: 82.5mm (3.25″)
Net Weight : 1.9 kg/pc
420 (2Cr13) stainless steel replacement rotor with perfect heat dissipation, provides strong, reliable braking power, can match all types of brake pads.
HRC 36+- 2 Heat treatment for the material avoiding warped.
Drilled design to remove excess heat, gas, and material from the friction surface – but without weakening the heat resistance of the disc
Precision ground for maximum flatness.
Features:
- Laser cut for precision and heat treatment
- Made of stainless, rust resistant and high polished
- This floating rotor features a steel inner carrier that is shaped to accent the wheel, with a polished and slotted stainless steel outer disc that is precision-riveted in place.
- Good heat dissipation, provides strong, reliable braking power, can match all types of brake pads
- New scraper slot system to keep your brake system clean and run cooler
Fits for Harley DavidsonSportster models
XL 50 883 50th Anniversary Sporstster 2007
XLH Sportster 883 2000-2003
XLH Sportster 883 R Flat Track 2000-2003
XL Sportster 883 Hugger 2000-2003
XL Sportster 53c Custom (883cc) 2000-2003
XL 883 Sportster Standard 2004-2008
XL 883 C Sportster Custom 2004-2010
XL 883 L 883 Low 2004-2010
XL 883 L Superlow 2011-2013
XL883 N Iron 2009-2010
XL883 N Iron(Cast Wheel) 2011-2013
XL883 R 100th Anniversary Edition 2003
XL883 R Sportster R 2005-2013
XL883 R Roadsterc 2010
XL883 R Roadster (Cast Wheel) 20011-2013
XL 1200 R Sportster Roadster 2004-2008
XL 1200 C Sportster Custom 2004-2010
XL 1200 C Sportster Custom (Cast & Spoke Wheels) 2011-2013
XL 1200 L Sportsetr Low (Spoke wheel) 2007-2011
XL 1200 L Sportster Low (Cast Wheel ) 2007-2011
XL 1200 N Nightster (Spoke wheel) 2008-2012
XL 1200 V Seventy Two 2012-2013
